Specifications:
- System: 2-Ways, 2 Speakers
- Woofer Unit: 380mm (15 inch) Cone Type Woofer with 76mm Coil 1x unit
- Tweeter Unit: 33mm Throat, 76mm Coil Diaphragm Assembly Type 1x unit
- Frequency Response: 70Hz~18,000Hz (±3dB)
- Sensitivity: 105dB/W/m
- Max SPL Peak: 139dB/m
- Max SPL Continuous: 133dB/m
- Max Input Power: 2,400W
- Rating Input Power: 600W (Public Addresses speaker type)
- Recommended Amplifier: 800W (DAP-8000)
- HF Protections: Poly Switch Circuit Breaker
- Crossover Frequency: 1.2KHz
- Horizontal Coverage: 60°
- Vertical Coverage: 60°
- Connector: Neutrik Speakon NL4MP 2x
- Impedance: 8Ω
- Dimension:
- 16.3" x 27.2" x 18.1"
- 414mm x 690mm x 460mm
- Weight:
- 74.08 lbs
- 33.6 kg per piece
- Enclosure Material: 15/21mm Birch Plywood
- Grille: 5.5mm Custom Hexagon perforated steel grille
- Finish: Painted Finish
- Handling position: 12 x M10 Type inserts
- Pole Mount: ⱷ36mm bottom support base
